前面我们介绍了如何使用 spire.presentation 添加或删除powerpoint常规图形到幻灯片，该文将详细介绍如何使用c#添加圆角矩形到幻灯片并设置圆角矩形的半径。

using spire.presentation;
using spire.presentation.drawing;
using system.drawing;
namespace roundrectangle
{
    class program
    {
        static void main(string[] args)
        {
            presentation presentation = new presentation();
            //插入圆角矩形并设置其半径
            presentation.slides[0].shapes.insertroundrectangle(0, 60, 90, 100, 200, 36);
            //添加圆角矩形并设置其半径
            iautoshape shape = presentation.slides[0].shapes.appendroundrectangle(260, 90, 100, 200, 80);
            //设置圆角矩形的填充颜色
            shape.fill.filltype = fillformattype.solid;
            shape.fill.solidcolor.color = color.seagreen;
            shape.shapestyle.linecolor.color = color.white;
            //旋转90度
            shape.rotation = 90;

            //保存文档
            presentation.savetofile("result.pptx", fileformat.pptx2013);

        }
    }
}

imports spire.presentation
imports spire.presentation.drawing
imports system.drawing
namespace roundrectangle
	class program
		private shared sub main(args as string())
			dim presentation as new presentation()
			'插入圆角矩形并设置其半径
			presentation.slides(0).shapes.insertroundrectangle(0, 60, 90, 100, 200, 36)
			'添加圆角矩形并设置其半径
			dim shape as iautoshape = presentation.slides(0).shapes.appendroundrectangle(260, 90, 100, 200, 80)
			'设置圆角矩形的填充颜色
			shape.fill.filltype = fillformattype.solid
			shape.fill.solidcolor.color = color.seagreen
			shape.shapestyle.linecolor.color = color.white
			'旋转90度
			shape.rotation = 90
			'保存文档
			presentation.savetofile("result.pptx", fileformat.pptx2013)
		end sub
	end class
end namespace

效果图:
